Smooth milling thanks to flutes with 15° helix angle
Chamfering of the core hole with a face chamfer
For the specific pitch
Cross-dimension profile design for more flexibility
Time savings by reducing the required number of tool variants
Application
P
Steel <43 HRc
100 – 200
0,04 x P
M
SS <33HRc
40 – 120
0,035 x P
K
cast iron
100 – 300
0,045 x P
N
n.f.
100 – 300
0,06 x P
S
heat res. Ti-all.
40 – 80
0,025 x P
H
Available dimensions
M
MF
UNC
UNF
G
NPT
M3 – M16
M5x0,5 – M16x1,5
Nr.10 – 3/4
Nr.10 – 3/4
1/8 – 1“
1/16 – 2“
Produktdetails NORIS SFR15 UNI MKB 2xD K20 ACR
Coating
ACR ALUMINIUMCHROMNITRID
New ACR coating with optimal coating adhesion and extremely smooth surface to ensure long tool life and high process reliability when machining a wide range of materials
Substrate
Carbide
Tough-hard ultrafine grain grade for the processing of extremely hard materials, cast materials, composite materials, plastics and graphite
Coolant bore
Ensuring cooling lubrication and chip evacuation during machining
Geometry
UNI
New developed geometry to ensure long tool life and high process reliability when machining a wide range of materials
SFR15 (R15° flutes)
Stable flutes for 2xD thread depth
Profile
In ranges across dimensions, specific pitch
Chamfer
Chamfering section flexible over front part
Product-Highlights
Tool features
Universal use possible
Special developed carbide for extra toughness
Chamfering section over front part
Special flute design R15° for smooth milling
Advantages
Right- and left hand threads
Blind- and through holes
Best chip evacuation
Cross-dimension profile design for more flexibility
Customer benefits
For universal applications = higher flexibility
High production safety = avoid extra work and extra costs
